TA-TPV Winches
TA-TPV Winches: A New Generation Of Manual Winches For Integrators
The Goliath TA-TPV winches are designed to accommodate a wide range of applications, ensuring comfort, safety, and optimal performance for the user.
Safety Features and Removable Crank: The Safest Winch on the Market
The Goliath TA-TPV winches feature a permanent internal self-brake that activates automatically under load. This mechanism functions independently of the crank, allowing for safe disconnection and preventing unauthorised use by removing the crank.
To comply with the EN13157-A1 standard and European regulations, the self-brake is a mandatory feature on all winches.
Our TA-TPV manual winch meets the EN13157 A1 standard and is CE marked, guaranteeing quality and compliance.
Powerful Performance: Handle Loads up to 1500 kg
Goliath TA-TPV winches offer a versatile load capacity range from 100 to 1500 kg, ensuring optimal performance for various applications.
Enhanced Comfort: Reduced Effort on the handle
The TA-TPV manual winches are designed to minimise crank effort, enhancing user comfort. Our latest generation self-brake significantly reduces the force required during descent by up to 50%.
Dual-Speed Models: Effortless Lifting
Certain models feature a dual-speed mechanism, cutting lifting effort by 50% for variable loads or high lifting heights.
Switching speeds is easy and safe: simply disconnect the crank from its initial drive shaft and reposition it on the second shaft. This operation can be carried out safely at any time!
TR9: Competitive Entry-Level Solution
Ideal for loads under 250 kg, the TR9 model provides a cost-effective solution for integrators, combining performance and affordability.
Functional Design
The TA-TPV galvanized steel winches feature a sleek black protective cover, offering both enhanced aesthetics and reinforced protection.
Versatile Installation Solutions
TA-TPV winches come standard with multiple installation options, ensuring seamless integration with your lifting devices at no additional cost.
- Mounting Options: Console or wall mounting.
- Crank Configurations: Fixed or removable crank, with positioning on either the right or left side.
- Double Crank Solution: Available for specific needs.
Customisable Versions
Thanks to their adaptable design, TA-TPV winches can be customised to meet your specific requirements, enabling large-volume production of tailored solutions.
