CHS Hydraulic Trolleys
CHS hydraulic trolleys
The new range of CHS handling trolley is based on the concept of lifting by adjustable hydraulic stands that has made the BHS range so successful.
These trolleys are equipped with independent hydraulic stands for handling motorboats and sailboats up to 26T, stored on fixed cradles. Their advantages?
- Individual adjustment and lifting of the stands.
- Wide 85 shore elastomer swivel shoes.
- Adjustable pads.
- Anti-fall safety device on each jack.
- Numerous options available.
Technical Details
Our CHS trolleys are built according to your dimensional specifications and are equipped with :
- A reinforced chassis and multiple wheel systems to cope with different load distributions.
- Stands available in several sizes to fit all your hulls.
- New rear lifting equipment for long and/or IPS hulls (optional), plus a double set of stands.
- A manual or electric control system, enabling the lifting points to be used simultaneously, or in sections, to lift the hull smoothly and progressively.
- Several anti-fall safety systems integrated into the hydraulic system to ensure your safety.
CHS
| Modèle | Playload capacity (kg) | Chassis length (mm) | Internal passage width (mm) | Nb of wheels (front/back) | No. of adjustable stands | Lifting point (back) | Type of 85 shore pads | Action |
|---|---|---|---|---|---|---|---|---|
| CHS 8T | 8T | 5810 | standard : 1550 long hull option + 1500mm | 2 + 4 | 4 | 2 | 4 quadruples | Reseller Personalised Quote |
| CHS 10T | 10T | 5810 | standard : 1550 long hull option + 1500mm | 3 + 4 | 6 | 2 | 6 triples | Reseller Personalised Quote |
| CHS 14T | 14T | 7290 | standard : 1650 long hull option + 1500mm | 3 + 8 | 6 | 2 | 6 triples | Reseller Personalised Quote |
| CHS 16T | 16T | 7300 | standard : 1650 long hull option + 1500mm | 4 + 8 | 6 | 2 | 6 quadruples | Reseller Personalised Quote |
| CHS 22T | 22T | 7530 | standard : 1800 long hull option + 1500mm | 5 + 8 | 8 | 2 | 8 quadruples | Reseller Personalised Quote |
CHS OPTION
| OPTIONS | CHS 8T | CHS 10T | CHS 14T | CHS 16T | CHS 22T | Action |
|---|---|---|---|---|---|---|
| 2 add. Lifting points | MP-OPT001/CHS8T | MP-OPT001/CHS10T | MP-OPT001/CHS14T | MP-OPT001/CHS16T | MP-OPT001/CHS22T | Reseller Personalised Quote |
| Long hull & IPS | MP-OPT002/CHS8T | MP-OPT002/CHS10T | MP-OPT002/CHS14T | MP-OPT002/CHS16T | MP-OPT002/CHS22T | Reseller Personalised Quote |
| Sailboat pack | MP-OPT003/CHS8T | MP-OPT003/CHS10T | MP-OPT003/CHS14T | MP-OPT003/CHS16T | MP-OPT003/CHS22T | Reseller Personalised Quote |
| Adjustable stand kit | MP-OPT004/CHS8T | INCLUDED | INCLUDED | INCLUDED | INCLUDED | Reseller Personalised Quote |
| Hydroelectric contro | MP-OPT005/CHS8T | MP-OPT004/CHS10T | MP-OPT004/CHS14T | INCLUDED | INCLUDED | Reseller Personalised Quote |
| Casing and battery | MP-OPT006/CHS8T | MP-OPT005/CHS10T | INCLUDED | INCLUDED | INCLUDED | Reseller Personalised Quote |
| PPS tyres | MP-OPT007/CHS8T | MP-OPT006/CHS10T | MP-OPT005/CHS14T | MP-OPT005/CHS16T | MP-OPT005/CHS22T | Reseller Personalised Quote |
| Wheel lock / road signalling | MP-OPT008/CHS8T | MP-OPT007/CHS10T | MP-OPT006/CHS14T | MP-OPT006/CHS16T | MP-OPT005/CHS22T | Reseller Personalised Quote |
| Stand storage box | MP-OPT009/CHS8T | MP-OPT008/CHS10T | MP-OPT007/CHS14T | MP-OPT007/CHS16T | MP-OPT007/CHS22T | Reseller Personalised Quote |
