Winch TS

Ref.:

Treuils-TS

From €109.17 incl. vat

In stock

Only %1 left

Goliath winch exclusively dedicated to the nautical application. For boats up to 3 tons.
- New generation permanent safety brake
- Free unwinding of the strap
- Hood and guide strap
- Sold with strap and crank

2 speeds Effort <50%
European Standard EN13157-A1
Removable handle
Free unwinding of the sling

GOLIATH WINCH SIMPLICITY SAFETY AND COMFORT

Unlock the brake by pressing downward the strap guide, freely unwind the strap, and tie your boat.
Turn the handle, the strap guide gets back up, the safety device is automatically activated. (3)
You can take your boat out of the water.
Safely change the speed at any time to reduce force by 50%. (4)
Remove the handle.
Quick strap rewinding and protected strap. (5)

Attention: The winch is not a tie-down point; use the QuickFlex tie-down system.

See QuickFlex

Model	Name	Pulling capacity	Drum hub ø	Strap length	Handle length (mm)	Number of speeds	Price Goliath-Store*	Action
PF70800B	TS800	800kg	20mm	8m	250mm	1	€109.17 Incl. VAT
PF70900B	TS900	900kg	20mm	8m	290mm	1	€117.87 Incl. VAT	Reseller Personalised Quote
PF701200B	TS1200	1200kg	20mm	8m	250mm	2	€147.68 Incl. VAT	Reseller Personalised Quote
PF701600B	TS1600	1600kg	20mm	8m	290mm	2	€171.81 Incl. VAT	Reseller Personalised Quote
PF702200	TS2200	2200kg	20mm	8m	290mm	2	€231.47 Incl. VAT	Reseller Personalised Quote
PF703000	TS3000	3000kg	27mm	13m	290mm	2	€437.35 Incl. VAT

Standards And Safety

The norm EN13157 A1 defines the essential criteria to ensure your safety and allow us the put the CE stamp on our winches (in the case of use in the European Union)

Warning! The CE stamp can be based on a self-certification of the importer or the manufacturer, which sadly lead to an abusive usage and the non-compliance with the CE standards. Please be careful

A winch that is not in compliance with the EN13157 A1 is not CE, which renders the lifting product not in compliance with the directive on machinery safety for which you can be held liable.

You’ll find bellow a few of the compulsory criteria for the CE qualification of a winch. Of course, it shouldn’t be summarize just by these elements. Our goal is to allow you to visually identify some key elements to look out for:

Safety auto-brake: the auto-brake is mandatory for lifting: As a reminder, the EN13157 A1 norm defined lifting as a change in height during movement. It can includes horizontal or vertical movement of the load and every other combinaisons.
Handle: Must not be removable if the auto-brake depends on it
Protective crankcase: the internal and external sprocket as well as the prominent elements of the system (ie. The drum) must be protected.
Drum: the diameter of the drum hum varies depending on the cable and measures between 35 and 72mm (for manual winches up to 1000kg) Otherwise, the cable fiber can be damaged and can load to the cable breakage. The drum hub must also resist to crushing.
Cable or sling securing: The anchoring of the cable or sling of the winch must respect the norms and resist the nominal load 3 times
Slings and cables: They must be in compliance with the current European norm. Beware of slings that are too fragile! If they are damaged, their breaking can have sometime very dramatic consequences.

Downloads

User manual

Dimensions
